Product Details:
Payment & Shipping Terms:
|
Product Name: | Cutting Plotter With CNC | Model: | DCG701713 |
---|---|---|---|
Effective Cutting Area: | 1700*1300mm | Max Speed: | 1200mm/s |
Smallest Cutting Diameter: | 3.2mm | Cutting Accuracy: | 0.27mm |
Cutting Materials: | Foam, EVA, PVC,PP Sheets, Polypropylene Corrugated Sheet ,corrugated Cardboard Up To 60 Mm, Cartons, Laminates, Printing Blankets, Coating Plates, Preprinted Vinyl Films, Reflective Sheeting, Textile And Technical Fabrics, Soft, | Cutting Materials: | Foam, EVA, PVC,PP Sheets, Polypropylene Corrugated Sheet ,corrugated Cardboard Up To 60 Mm, Cartons, Laminates, Printing Blankets, Coating Plates, Preprinted Vinyl Films, Reflective Sheeting, Textile And Technical Fabrics, Soft, |
Cutting Thickness: | Less Than 100mm | Size: | 1300*1000mm, 1800*1500mm, 2500*1600mm, 3000*1600mm, 3000*2000mm, Customerised |
Size: | 1300*1000mm, 1800*1500mm, 2500*1600mm, 3000*1600mm, 3000*2000mm, Customerised | Size: | 1300*1000mm, 1800*1500mm, 2500*1600mm, 3000*1600mm, 3000*2000mm, Customerised |
Size: | 1300*1000mm, 1800*1500mm, 2500*1600mm, 3000*1600mm, 3000*2000mm, Customerised | Tools: | Oscillating Knife, Creasing Wheel, Pen, Laser Light, |
Tools: | Pneumatic Tool, Vcut, Kiss Cut, CCD | TABLE: | Flatbed, Conveybelt, |
High Light: | die cutting equipment,desktop die cutting machine |
pressure control electronic die cutting machine plastic cut shin paper cut
Introduction
ABOUT US
1.20 years of experience in CNC cutting technology;
2.The first and biggest CNC cutting machine manufacturer in China;
3.We focus on the research and development of CNC knife-cutting technology and related CAD software over the past 20 years;
4.The quality and service are regarded as the life of our corporation;
5.We will never be satisfied until you are satisfied;
6.Our engineering team never stop to improve our machine and upgrade our software;
7.AOKE is based in Shanghai, aiming at the global market.
GUARANTEE & AFTER SALE SERVICE
1.One year guarantee for whole machine except consumables such as knife blade, mat.
2.You are welcome to our company to have a professional trainning and observation.
3.Calling or door-to-door service.
4.24 hour online and hot line services.
After-sale service
First, warmly welcome you to our head office to have a professional training and observation.
We can also dispatch our technician to your place, offer training and help solve your any questions about our cutting machine.
If you need help, you can send email to us or contact us by skype or MSN online chatting tools.
We offer 24h online service.
Specification:
Model | DCG701209 | DCG700906 | DCG710906 | DCG711209 | ||
Effective cutting area | 1200*900mm | 900*600mm | 1200*900mm | |||
Configuration | Pen, pressure control knife, laser position | |||||
Way of fixing paper way | Vacuum absorbing | Electrostatic | ||||
Max speed | 1000mm/s | |||||
Cutting thickness | <1mm | |||||
Cutting precision | <0.01mm | |||||
Voltage | 220V 50HZ | |||||
Transmitting port | parallel port/RSC232 serial port | |||||
Instruction set | HPGL DXF | |||||
Occupy dimension(L*W*H) | 1635*1365*1080mm | 1335*1065*1080mm | 1635*1365*1080mm | |||
Note | Other size can be customized. |
Samples
Optional
Video registration system
