Variable Spindle Control Paper Box Making Machine / Carton Box Cutting Machine

Variable Spindle Control Paper Box Making Machine / Carton Box Cutting Machine

Variable Spindle Control Paper Box Making Machine / Carton Box Cutting Machine
Variable Spindle Control Paper Box Making Machine / Carton Box Cutting Machine Variable Spindle Control Paper Box Making Machine / Carton Box Cutting Machine

Large Image :  Variable Spindle Control Paper Box Making Machine / Carton Box Cutting Machine Get Best Price

Product Details:
Place of Origin: CHINA
Brand Name: MAXWELL
Certification: CE
Model Number: MEC
Payment & Shipping Terms:
Minimum Order Quantity: 1 UNIT
Price: 3000USD
Packaging Details: WOODEN BOX
Delivery Time: WITHIN ONE MONTH
Payment Terms: TT
Supply Ability: 30 sets per month
Detailed Product Description
Product Name: Flatbed Digital Cutter Model: DCZ70
Effective Cutting Area: 2500*1600mm 1700*1300mm 1300*1000mm Max Aped: 1400mm/s
Smallest Cutting Diameter: 6mm Maximum Cutting Thickness: 30mm
High Light:

sheet board cutting machine

,

gift box making machine

,

oscillating blade paper box cutting machine

Carton box making Cutting plotter corrugated box paper Carton Sample digital cut with oscillating blade and folding



Introduction:

Productivity
The new DCZ 7 Series machines provide fast and flexible solutions to prototyping and short run production requirements. Automating your finishing department increases productivity and reduces bottlenecks, this is clear to see. With the ability to prototype, the DCZ 7 Series machine also allows your design team to be more creative.

Flexibility
The high speed, high accuracy digital servo drives provide smooth and reliable operation Versatile tooling options ensure that you have the ability to finish a vast range of materials quickly and easily. Adding extra tooling, such as the powerful 1KW router, extends the range of materials that can be cut far beyond those that a single point knife cutting system can handle. Because tables come in an extensive range of sizes you can be confident of finding a solution that fits your requirements perfectly.

Tooling
The DCZ 7 Series tool head comprises 2 interchangeable, tangentially driven tool modules and a Pen, incorporating the following, standard set of tools.

  • Electronic Oscillating Knife – with variable oscillating control, max 12,000rpm. Suitable for cutting a variety of materials, up to 15mm in thickness.
  • Drag Knife – With a selection of blade types and angles to suit most materials Creasing Tool – with interchangeable creasing profiles. Suitable for creasing a variety of both fluted and non-fluted packaging materials.
  • Pen Tool – Suitable for drawing on a variety of materials
  • Optional Router – with variable spindle control, speed max 50,000rpm Suitable for harder materials e.g. Acrylic, Plexiglas, wood and thin Aluminium. This tool is not part of the standard configuration but can be retrofitted if required.

Camera Registration
The video camera registration module fitted to the DCZ 7 Series gives you perfect cut to print registration every time. It minimizes the setup time on the machine, increases productivity and virtually eliminates errors and subsequent wastage. The module comprises a color video camera plus dedicated software which utilizes any style of registration mark.

Variable Spindle Control Paper Box Making Machine / Carton Box Cutting Machine 0



GUARANTEE & AFTER SALE SERVICE

1.One year guarantee for whole machine except consumables such as knife blade, mat.

2.You are welcome to our company to have a professional trainning and observation.

3.Calling or door-to-door service.

4.24 hour online and hot line services.



After-sale service
First, warmly welcome you to our head office to have a professional training and observation.
We can also dispatch our technician to your place, offer training and help solve your any questions about our cutting machine.
If you need help, you can send email to us or contact us by skype or MSN online chatting tools.

We offer 24h online service.



Specification:

Model DCZ702516 DCZ701713 DCZ701310
Effective cutting area 2500*1600mm 1700*1300mm 1300*1000mm
Configuration Oscillating knife,pen,creasing tool,drag knife
Max aped 1350mm/s
Smallest cutting diameter 6mm
Maximum cutting thickness 30mm
Control line and driver Servo
Precision ≤0.1mm
Data form HPGL,DXF,PDF
Voltage 220v±10%50Hz
Data port parallel port,serial port,USB port
Option Video registration system, V cut knife, foam knife
Occupy dimension(L*W*H) 3400*2460*1180mm 2600*2160*1180mm 2200*1860*1180mm
Note Other size can be customized.
